View ap2305gn detailed specification:
AP2305GN Halogen-Free Product Advanced Power P-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET Capable of 2.5V Gate Drive BVDSS -20V D Small Package Outline RDS(ON) 65m Surface Mount Device ID - 3.7A S RoHS Compliant & Halogen-Free SOT-23S G D Description Advanced Power MOSFETs from APEC provide the designer with the best combination of fast switching,low on-resistance and cost-effectiveness. G S The SOT-23S package is widely preferred for commercial-industrial surface mount applications and suited for low voltage applications such as DC/DC converters. Absolute Maximum Ratings@Tj=25oC(unless otherwise specified) . Symbol Parameter Rating Units VDS Drain-Source Voltage - 20 V VGS Gate-Source Voltage + 12 V Drain Current3, VGS @ 4.5V ID@TA=25 -3.7 A Drain Current3, VGS @ 4.5V ID@TA=70 -3 A IDM Pulsed Drain Current1 -10 A PD@... See More ⇒
