View asdm3400za detailed specification:
ASDM3400ZA 30V N-Channel MOSFET General Features Product Summary High Power and current handing capability VDS 30 V Lead free product is acquired RDS(on),Typ.@ VGS=10 V 29 m Surface Mount Package ID 5.8 A Available in SOT23 Package Applications PWM applications Load switch Power management SOT23 Top View N-channel Absolute Maximum Ratings TA=25 C unless otherwise noted Parameter Symbol Maximum Units Drain-Source Voltage VDS 30 V Drain-Source Voltage VDS 30 V Gate-Source Voltage VGS 12 V TA=25 C 5.8 Continuous Drain ID Current TA=70 C 4.9 A Pulsed Drain Current C IDM 30 TA=25 C 1.4 PD W Power Dissipation B TA=70 C 0.9 Junction and Storage Temperature Range TJ, TSTG -55 to 150 C Thermal Characteristics Parameter Symbol Typ Max Units Maximum Junction-to-Ambient A t 10s 70 90 C/W R JA Maximum Junction-t... See More ⇒
