View jmh65r190apln datasheet:

jmh65r190aplnjmh65r190apln

JMH65R190APLN650V SuperJunction Power MOSFETFeatures Product SummaryParameter Value Unit Extremely Low Gate Charge VDS650 V Excellent Output Capacitance (Coss) Profile VGS(th)_Typ3.5 V Fast Switching Capability ID (@ VGS = 10V) (1) 17.4 A 100% UIS Tested, 100% Rg Tested RDS(ON)_Typ (@ VGS = 10V)169 m Eoss@400V5.2 J Pb-free Lead Plating Halogen-free and RoHS-compliantApplications Telecom / Server Power Supplies Industrial Power Supplies UPS / Solar Lighting / Charger / Adapter DFN8080-4L Pin ConfigurationTop ViewBottom ViewTop View54321Ordering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMH65R190APLN-13 DFN8080-4L 4 H65R190A 1 -55 to 150 13-inch Reel 3000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value Un
