View jmsh0401ptsq datasheet:

40V, 381A, 0.9m N-channel Power SGT MOSFETJMSH0401PTSQProduct SummaryFeatures Ultra-low ON-resistance, RDS(ON)ParametersValue Unit Low Gate ChargeVDSS 40 V 100% UIS TestedVGS(th)_Typ 2.6 V 100% Vds TestedID(@VGS=10V) 381 A Halogen-free; RoHS-compliantRDS(ON)_Typ(@VGS=10V 0.9 mW AEC-Q101 QualifiedApplications Load Switch PWM Application General Automtoive ApplicationDG SSchematic DiagramPowerJE7x8Ordering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMSH0401PTSQ-13 PowerJE7x8SH0401PQ 1 Tape&Reel 2000 10000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 40 VVGS Gate-to-Source Voltage 20 VTC = 25 381CIDContinuous Drain Current ATC = 100 269CIDM Refer to Fig.4 APulsed
