View jmsh0402pg datasheet:

40V, 202A, 1.4m N-channel Power SGT MOSFETJMSH0402PGProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TestedVDSS 40 V 100% Vds TestedVGS(th)_Typ 2.7 V Halogen-free; RoHS-compliantID(@VGS=10V) 202 ARDS(ON)_Typ(@VGS=10V 1.4 mWApplications Load Switch PWM Application Power ManagementDG SPDFN5X6-8LSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMSH0402PG PDFN5x6-8LSH0402P 1 Tape&Reel 5000 50000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 40 VVGS Gate-to-Source Voltage 20 VTC = 25 202CIDContinuous Drain Current ATC = 100 128CIDM Refer to Fig.4 APulsed Drain Current (1)EAS 459 mJSingle Pulsed Avala
