View jmsh0403pghwq datasheet:

40V, 140A, 3.0m N-channel Power SGT MOSFETJMSH0403PGHWQProduct SummaryFeatures Ultra-low ON-resistance, RDS(ON)ParametersValue Unit Low Gate ChargeVDSS 40 V 100% UIS TestedVGS(th)_Typ 3.1 V 100% Vds TestedID(@VGS=10V) 140 A Halogen-free; RoHS-compliantRDS(ON)_Typ(@VGS=10V 3.0 mW AEC-Q101 QualifiedApplications Load Switch PWM Application General Automtoive ApplicationPDFN5X6-8L-HWSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMSH0403PGHWQ-13 PDFN5x6-8L-HWH0403PHQ 1 Tape&Reel 5000 50000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 40 VVGS Gate-to-Source Voltage 20 VTC = 25 140CIDContinuous Drain Current ATC = 100 99CIDM Refer to Fig.4 A
