View jmsh0602pgq datasheet:

60V, 179A, 1.6m N-channel Power SGT MOSFETJMSH0602PGQProduct SummaryFeatures Ultra-low ON-resistance, RDS(ON)ParametersValue Unit Low Gate ChargeVDSS 60 V 100% UIS TestedVGS(th)_Typ 3.0 V 100% Vds TestedID(@VGS=10V) 179 A Halogen-free; RoHS-compliantRDS(ON)_Typ(@VGS=10V 1.6 mW AEC-Q101 QualifiedApplications Load Switch PWM Application General Automtoive ApplicationDG SPDFN5X6-8LSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMSH0602PGQ-13 PDFN5x6-8LSH0602PQ 1 Tape&Reel 5000 50000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 60 VVGS Gate-to-Source Voltage 20 VTC = 25 179CIDContinuous Drain Current ATC = 100 127CIDM Refer to Fig.4
