View jmsh0606pgq datasheet:

60V, 118A, 4.5m N-channel Power SGT MOSFETJMSH0606PGQProduct SummaryFeatures Ultra-low ON-resistance, RDS(ON)Parameters Value Unit Low Gate ChargeVDSS 60 V 100% UIS TestedVGS(th)_Typ 2.8 V 100% Vds TestedID(@VGS=10V) 118 A Halogen-free; RoHS-compliant RDS(ON)_Typ(@VGS=10V 4.5 mW AEC-Q101 QualifiedApplications Load Switch PWM Application General Automtoive ApplicationDG SPDFN5X6-8LSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice Marking MSL Form Package Reel(pcs)(pcs)JMSH0606PGQ-13 SH0606PQ 1 Tape&Reel PDFN5x6-8L 5000 50000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Symbol Parameter Value UnitVDS Drain-to-Source Voltage 60 VVGS Gate-to-Source Voltage 20 VTC = 25 118CID Continuous Drain Current ATC = 100 84CIDM Refer to Fig.4 APuls
