View jmsh1002nc jmsh1002ne datasheet:

jmsh1002nc_jmsh1002nejmsh1002nc_jmsh1002ne

JMSH1002NCJMSH1002NE100V 2.2m N-Ch Power MOSFETFeaturesProduct SummaryParameter Value Unit Ultra-low RDS(ON) VDS100 V Low Gate Charge VGS(th)2.8 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 284 A RDS(ON) (@ VGS = 10V)2.2 m Pb-free Lead Plating Halogen-free and RoHS-compliantApplications Motor Driving in Power Tool, E-vehicle, Robotics Current Switching in DC/DC & AC/DC (SR) Sub-systems Power Management in Telecom., Industrial Automation, CETO-220-3L Top ViewTO-263-3L Top ViewD DG GGDSSSOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1002NC-U TO-220-3L 3 SH1002N N/A -55 to 150 Tube 50JMSH1002NE-13 TO-263-3L 3 SH1002N 1 -55 to 150 13-inch Reel 800Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Val
