View jmsh1002ytl datasheet:

100V, 215A, 2.3m N-channel Power SGT MOSFETJMSH1002YTLProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TestedVDSS 100 V 100% Vds TestedVGS(th)_Typ 3.0 V Halogen-free; RoHS-compliantID(@VGS=10V) 215 A Pb-free platingRDS(ON)_Typ(@VGS=10V 2.3 mWApplications Load Switch PWM Application Power ManagementPowerJE10x12 Schematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMSH1002YTL PowerJE10x12SH1002Y 1 Tape&Reel 2000 10000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 100 VVGS Gate-to-Source Voltage 20 VTC = 25 215CIDContinuous Drain Current ATC = 100 136CIDM Refer to Fig.4 APulsed Drain Current (1)EAS 95
