View jmsh1003ag datasheet:
JMSH1003AG100V 2.8m N-Ch Power MOSFETProduct SummaryFeaturesParameter Value Unit Ultra-low RDS(ON) VDS100 V Low Gate Charge VGS(th)_Typ2.7 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 144 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)2.8 m Halogen-free and RoHS-compliantApplications Power Managerment in Telecom., Industrial Automation, CE Current Switching in DC/DC & AC/DC Sub-systems Motor Driving in Power Tool, E-vehicle, RoboticsPDFN5x6-8LPin ConfigurationTop View DBottom ViewTop View1827G3645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1003AG-13 PDFN5x6-8L 8 H1003A 1 -55 to 150 13-inch Reel 5000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Source Voltage VDS 10
