View jmsh1008ac jmsh1008ae datasheet:

jmsh1008ac_jmsh1008aejmsh1008ac_jmsh1008ae

JMSH1008ACJMSH1008AE100V 6.8mW N-Ch Power MOSFETProduct SummaryFeaturesParameter Value Unit Ultra-low RDS(ON) VDS 100 V Low Gate Charge VGS(th)_Typ 2.8 V 100% UIS Tested, 100% R Testedg ID (@ VGS = 10V) (1) 112 A RDS(ON)_Typ (@ VGS = 10V) 6.8 mW Pb-free Lead Plating Halogen-free and RoHS-compliantApplications Power Managerment in Telecom., Industrial Automation, CE Current Switching in DC/DC & AC/DC (SR) Sub-systems Motor Driving in Power Tool, E-vehicle, RoboticsTO-220-3L Top ViewTO-263-3L Top ViewD DG GGDSSSOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1008AC-U TO-220-3L 3 SH1008A N/A -55 to 150 Tube 50JMSH1008AE-13 TO-263-3L 3 SH1008A 3 -55 to 150 13-inch Reel 800(@ TA = 25C unless otherwise specified)Absolute Maximum Ratings Parameter Symbo
