View jmsh1010pc datasheet:
100V, 75A, 7.9m N-channel Power SGT MOSFETJMSH1010PCProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TestedVDSS 100 V 100% Vds TestedVGS(th)_Typ 2.9 V Halogen-free; RoHS-compliantID(@VGS=10V) 75 ARDS(ON)_Typ(@VGS=10V 7.9 mWApplications Load Switch PWM Application Power ManagementDG STO-220-3LSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Tube(pcs)(pcs)JMSH1010PC TO-220-3LSH1010P N/A Tube 50 5000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 100 VVGS Gate-to-Source Voltage 20 VTC = 25 75CIDContinuous Drain Current ATC = 100 48CIDM Refer to Fig.4 APulsed Drain Current (1)EAS 165 mJSingle Pulsed Avalanche Ener
