View pm561ba datasheet:

PM561BAP-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID51m @VGS = -10V-30V -4ASOT-23(S)ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVGSGate-Source Voltage 20 VTA = 25 C-4IDContinuous Drain CurrentTA = 70 AC-3IDM-16Pulsed Drain Current1TA = 25 C1.4PDWPower Dissipation3TA = 70 C0.9Tj, TstgOperating Junction & Storage Temperature Range -55 to 150 CTHERMAL RESISTANCE RATINGSTHERMAL RESISTANCE SYMBOL TYPICAL MAXIMUM UNITSRqJAt10s 90Junction-to-Ambient2C / WSteady-State RqJA 130Junction-to-Ambient21Pulse width limited by maximum junction temperature.2The value of RqJA is measured with the device mounted on 1in2 FR-4 board with 2oz.Copper.9The Power dissipation is based on RqJA t 10s value.REV
