View 2n3904-t18 datasheet:

2N3904-T18 MECHANICAL DATA Dimensions in mm (inches) 5.84 (0.230)5.31 (0.209)4.95 (0.195)4.52 (0.178)GENERAL PURPOSE HERMETIC NPN SILICON TRANSISTOR FEATURES SILICON NPN EPITAXIAL TRANSISTOR0.48 (0.019) HERMETIC TO18 PACKAGE 0.41 (0.016)dia. HI-REL SCREENING OPTIONS AVAILABLE HIGH SPEED SATURATED SWITCHING2.54 (0.100)Nom.APPLICATIONS A hermetically sealed TO18 version of the 3 1popular 2N3904 plastic part intended for high 2reliability applications. TO-18 (TO-206AA) Underside View Pin 1 Emitter Pin 2 Base Pin 3 Collector ABSOLUTE MAXIMUM RATINGS TCASE = 25C unless otherwise stated VCBO Collector - Base Voltage 60V VCEO Collector - Emitter Voltage (IB = 0) 40V VEBO Emitter Base Voltage (IC = 0) 6.0V IC Continuous Collector Current 200mA PD Total Power Dissipation at TA = 25C 0.31W
