View 2n3904 datasheet:

JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD TO-92 Plastic-Encapsulate Transistors 2N3904 TRANSISTOR (NPN) TO-92 FEATURE NPN silicon epitaxial planar transistor for switching and 1. EMITTER Amplifier applications 2. BASE As complementary type, the PNP transistor 2N3906 is Recommended 3. COLLECTOR This transistor is also available in the SOT-23 case with the type designation MMBT3904 MAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter Value UnitVCBO Collector-Base Voltage 60 V VCEO Collector-Emitter Voltage 40 V VEBO Emitter-Base Voltage 6 V IC Collector Current -Continuous 0.2 A PC Collector Power Dissipation 0.625 W TJ Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Ta=25 unless otherwise specified) Parameter Symbol Test conditions Min Typ Max Unit Col
