View 2sc2412kgp datasheet:

CHENMKO ENTERPRISE CO.,LTD2SC2412KGPSURFACE MOUNT General Purpose Transistor VOLTAGE 50 Volts CURRENT 0.15 AmpereAPPLICATION* Small Signal Amplifier .FEATURE* Surface mount package. (SOT-23)SOT-23* Low saturation voltage VCE(sat)=-0.4V(max.)(IC=50mA) * Low cob. Cob=2.0pF(Typ.)* PC= 200mW (mounted on ceramic substrate).* High saturation current capability.(1)CONSTRUCTION(3)* NPN Silicon Transistor* Epitaxial planner type(2)MARKING( ) ( ).055 1.40 .028 0.70* HFE(Q):ND( ) ( ).047 1.20 .020 0.50* HFE(R):C4G-( ).103 2.64* HFE(S):GT.086 (2.20)C (3)( ).045 1.15CIRCUIT( ).033 0.85Dimensions in millimeters SOT-23(1) (2)B EMAXIMUM RATINGES ( At TA = 25oC unless otherwise noted )RATINGS CONDITION SYMBOL MIN. MAX. UNITSCollector - Base Voltage Open Emitter VCBO - 60 VoltsCollector - Emitter Voltage Open Base V
