View 2sd965-r 2sd965-s datasheet:

2SD965TRANSISTOR (NPN) SOT-89FEATURES Low Collector-Emitter Saturation Voltage 1. BASE Large Collector Power Dissipation and Current 2. COLLECTOR Mini Power Type Package 3. EMITTER D: 965MARKINGMAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter Value UnitVCBO Collector-Base Voltage 42 V VCEO Collector-Emitter Voltage 22 V VEBO Emitter-Base Voltage 7.5 V ICM Collector Current 5 A PC Collector Power Dissipation 750 mW RJA Thermal Resistance From Junction To Ambient 167 /W Tj Junction Temperature 150 Tstg Storage Temperature -55~+150 ELECTRICAL CHARACTERISTICS (Ta=25 unless otherwise specified) Parameter Symbol Test conditions Min Typ Max Unit Collector-base breakdown voltage V(BR)CBO IC=100A,IE=0 40 VCollector-emitter breakdown voltage V(BR)CEO IC=1mA,IB=0 20 VEmitter-base breakdown voltage V(
