View cs630f a9h datasheet:

Silicon N-Channel Power MOSFET R CS630F A9H General Description VDSS 200 V CS630F A9H, the silicon N-channel Enhanced ID 9 A PD(TC=25) 30 W VDMOSFETs, is obtained by the self-aligned planar Technology RDS(ON)Typ 0.23 which reduce the conduction loss, improve switching performance and enhance the avalanche energy. The transistor can be used in various power switching circuit for system miniaturization and higher efficiency. The package form is TO-220F, which accords with the RoHS standard. Features Fast Switching Low ON Resistance(Rdson0.28) Low Gate Charge (Typical Data:13nC) Low Reverse transfer capacitances(Typical:10pF) 100% Single Pulse avalanche energy Test Applications AutomotiveDC Motor Control and Class D Amplifier. AbsoluteTc= 25 unless otherwise specified Symbol Parameter Rating Unit
