View h8205a datasheet:

Spec. No. : MOS200905 HI-SINCERITY Issued Date : 2009.02.27 Revised Date : 2010.06.30 MICROELECTRONICS CORP. Page No. : 1/4 H8205A 8-Lead Plastic TSSOP-8LDual N-Channel Enhancement-Mode MOSFET (20V, 6A) Package Code: TS H8205A Symbol & Pin Assignment Description 8 7 6 5 Pin 1: Drain Pin 2 / 3: Source 1 Q2This N-Channel 2.5V specified MOSFET is a rugged gate version of advanced Pin 4: Gate 1 Q1trench process. It has been optimized for power management applications with a Pin 5: Gate 2 Pin 6 / 7: Source 2 wide range of gate drive voltage (2.5V-10V) Pin 8: Drain 1 2 3 4Features RDS(on)=40m@VGS=2.5V, ID=5.2A; RDS(on)=25m@VGS=4.5V, ID=6A High Density Cell Design for Ultra Low On-Resistance High Power and Current Handing Capability Fully Characterized Avalanche Voltage and Current Ideal for Li ion Battery Pack
