View hgtg12n60c3d datasheet:

hgtg12n60c3d_hgtg12n60c3d_

S E M I C O N D U C T O R HGTG12N60C3D24A, 600V, UFS Series N-Channel IGBTwith Anti-Parallel Hyperfast DiodeJanuary 1997Features Package 24A, 600V at TC = 25oCJEDEC STYLE TO-247 Typical Fall Time . . . . . . . . . . . . . . 210ns at TJ = 150oCEC Short Circuit RatingG Low Conduction Loss Hyperfast Anti-Parallel DiodeDescriptionThe HGTG12N60C3D is a MOS gated high voltage switchingdevice combining the best features of MOSFETs and bipolartransistors. The device has the high input impedance of a MOS-FET and the low on-state conduction loss of a bipolar transistor.The much lower on-state voltage drop varies only moderatelybetween 25oC and 150oC. The IGBT used is the developmentTerminal Diagramtype TA49123. The diode used in antiparallel with the IGBT isthe development type TA49061. N-CHANNEL ENHANCEMENT MODEThe IGBT is ideal fo
