View jbl083m datasheet:

80V, 242A, 2.1m N-channel Power SGT MOSFETJBL083MProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TestedVDSS 80 V 100% Vds TestedVGS(th)_Typ 3.1 V Halogen-free; RoHS-compliantID(@VGS=10V) 242 ARDS(ON)_Typ(@VGS=10V 2.1 mWApplications Load Switch PWM Application Power ManagementSchematic DiagramPowerJE10x12 Pin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JBL083M PowerJE10x12BL083M 1 Tape&Reel 2000 10000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 80 VVGS Gate-to-Source Voltage 20 VTC = 25 242CIDContinuous Drain Current ATC = 100 171CIDM Refer to Fig.4 APulsed Drain Current (1)EAS 900 mJSingle Pulsed Avalanche Energ
