View jmsl0315ag datasheet:

JMSL0315AG30V 7.0m N-Ch Power MOSFETProduct SummaryFeaturesParameter Value Unit Low RDS(ON) VDS30 V High Current Capability VGS(th)_Typ1.7 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 44 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)7.0 m RDS(ON)_Typ (@ VGS = 4.5V)10.0 m Halogen-free and RoHS-compliantApplications Power Mgmt. in Computing, CE, Digital Lifestyle, IE 4.0, Communications Current Switching in DC/DC (H-bridge, Buck/Boost) & AC/DC (Inverting, SR) Load Switching over VBUS in Fast Charger, Half-bridging in Wireless Charger Motor Driving in Home Appliance, Robotics, VentilationPin ConfigurationPDFN5x6-8LTop ViewTop ViewBottom ViewD1 827G 3 645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSL0315AG-13 PDFN5x6-8L
