View mj21193r datasheet:

Order this documentMOTOROLAby MJ21193/DSEMICONDUCTOR TECHNICAL DATAPNP*MJ21193NPNSilicon Power Transistors*MJ21194The MJ21193 and MJ21194 utilize Perforated Emitter technology and are*Motorola Preferred Devicespecifically designed for high power audio output, disk head positioners and linearapplications.16 AMPERECOMPLEMENTARY Total Harmonic Distortion CharacterizedSILICON POWER High DC Current Gain hFE = 25 Min @ IC = 8 AdcTRANSISTORS Excellent Gain Linearity250 VOLTS High SOA: 2.5 A, 80 V, 1 Second250 WATTSCASE 107TO204AA(TO3)MAXIMUM RATINGSRating Symbol Value UnitCollectorEmitter Voltage VCEO 250 VdcCollectorBase Voltage VCBO 400 VdcEmitterBase Voltage VEBO 5 VdcCollectorEmitter Voltage 1.5 V VCEX 400 VdcCollector Current Continuous IC 16 AdcCollector Current Peak (
