UNISONIC TECHNOLOGIES CO., LTD MMBT5551 NPN SILICON TRANSISTOR HIGH VOLTAGE SWITCHING TRANSISTOR 3 DESCRIPTION The UTC MMBT5551 is a high voltage fast-switching NPN 1power transistor. It is characterized with high breakdown voltage, 2high current gain and high switching speed. SOT-23(JEDEC TO-236) FEATURES * High Collector-Emitter Voltage: VCEO=160V * High current gain ORDERING INFORMATION Pin Assignment Ordering Number Package Packing 1 2 3MMBT5551G-x-AE3-R SOT-23 E B C Tape ReelNote: Pin Assignment: E: Emitter B: Base C: Collector MARKING www.unisonic.com.tw 1 of 4 Copyright 2014 Unisonic Technologies Co., Ltd QW-R206-010. I MMBT5551 NPN SILICON TRANSISTOR ABSOLUATE MAXIUM RATINGS (TA= 25C, unless otherwise specified) PARAMETER SYMBOL RATINGS UNITCollector -Base Voltage VCBO 180 VCollector -Emitter Vo
