View mpsa13-14 datasheet:

MPSA13/MPSA14Plastic-Encapsulate TransistrosNPN Darlington Transistor1. EMITTER2. BASE 3. COLLECTOR1 2 3 TO-92Maximum Ratings(TA=25 C Unless O therwise Specified)Rating Symbol Value UnitVCEOCollector-Emitter Voltage 30V VCBOCollector-base Voltage 30 V VEBO10 V Emitter-base Voltage mACollector Current IC 500 Total Power Dissipation(TA=25C) 0.625PD W Operating Junction and Storage Temperature Range TJ,Tstg - 55~+150 CElectrical Characteristics(TA=25C Unless otherwise noted)Characteristic Symbol Min Max UnitCollector-base breakdown voltageV( BR) CB O V30 -IC=100A,IE=0Collector-emitter breakdown voltageV( BR)CE O30 -VIC=1mA,IB=0Emitter-base breakdown voltageV( BR)EB O - V10 IE=100A,IC=0Collector cut-off currentICB O0.1 AVCB=30V,IE=0Emitter cut-off currentIEBO0.1 AVEB=10V,IC=0
