MPSA13, MPSA14MPSA14 is a Preferred DeviceDarlington TransistorsNPN SiliconFeatureshttp://onsemi.com Pb-Free Packages are Available*COLLECTOR 3MAXIMUM RATINGS BASE2Rating Symbol Value UnitCollector-Emitter Voltage VCES 30 VdcCollector-Base Voltage VCBO 30 VdcEMITTER 1Emitter-Base Voltage VEBO 10 VdcCollector Current - Continuous IC 500 mAdcTotal Device Dissipation @ TA = 25C PD 625 mWDerate above 25C 5.0 mW/CTO-92Total Device Dissipation @ TC = 25C PD 1.5 WCASE 29Derate above 25C 12 mW/CSTYLE 1Operating and Storage Junction TJ, Tstg -55 to +150 CTemperature Range1122THERMAL CHARACTERISTICS 33STRAIGHT LEAD BENT LEADCharacteristic Symbol Max UnitBULK PACK TAPE & REELAMMO PACKThermal Resistance, Junction-to-Ambient RqJA 200 C/mWThermal Resistance, Junction-to-Case RqJC 83.3 C/mWMARKING DIAGRAM
