View nce15td120bd datasheet:

Pb Free ProductNCE15TD120BD1200V, 15A, Trench FS II Fast IGBTGeneral DescriptionUsing NCE's proprietary trench design and advanced FS (Field Stop) secondgeneration technology, the 1200V Trench FSII IGBT offers superior conduction andswitching performances, and easy parallel operation;Features Trench FSII Technology offering Very low VCE(sat) High speed switching Positive temperature coefficient in VCE(sat) Very tight parameter distribution High ruggedness, temperature stable behaviorSchematic diagramApplication Air Condition Inverters Motor drivesPackage Marking and Ordering InformationDevice Device Package Device MarkingNCE15TD120BD TO-263 NCE15TD120BDTO-263Absolute Maximum Ratings (T =25C unless otherwise noted)CSymbol Parameter Value UnitsV Collector-Emitter Voltage 1200 VCESV Gate- Emitter Vol
