View s8205a datasheet:

S8205ADual N-Channel Enhancement Mode Field Effect TransistorFEATURES Low on-resistance:V =20V,I =5A,R 25m@V =4.5VDS D DS(ON) GS Low gate charge For synchronous rectifier applications Surface Mount deviceSOT-23-6MECHANICAL DATA Case: SOT-23-6 Case Material: Molded Plastic. UL flammability Classification Rating: 94V-0 Moisture Sensitivity: Level 1 per J-STD-020 Weight: 0.3 grams (approximate)MAXIMUM RATINGS (T = 25C unless otherwise noted)AParameter Symbol Value UnitDrain-source voltage VDS20 VGate-source voltage VGS12 VContinuous drain current @T = 25C IA D5 APulsed drain current IDM25 APower dissipation PD1.25 WThermal resistance from Junction to ambient RJA100 C/WJunction and Storage temperature Range T ,TJ STG -55 ~+150 CELECTRICAL CHARACTERISTICS (T = 25C unless
