View tip29-a-b-c tip30-a-b-c datasheet:

TIP29, A, B, C (NPN),TIP30, A, B, C (PNP)Complementary SiliconPlastic Power TransistorsDesigned for use in general purpose amplifier and switchingapplications. Compact TO-220 AB package.http://onsemi.comFeatures1 AMPERE Pb-Free Packages are Available*POWER TRANSISTORSCOMPLEMENTARY SILICON40, 60, 80, 100 VOLTS, 80 WATTSMARKINGDIAGRAM4TO-220ABTIPxxxGCASE 221AAYWWSTYLE 1123TIPxxx = Device Code:29, 29A, 29B, 29C30, 30A, 30B, 30CA = Assembly LocationY = YearWW = Work WeekG = Pb-Free PackageORDERING INFORMATIONSee detailed ordering and shipping information in the packagedimensions section on page 2 of this data sheet.*For additional information on our Pb-Free strategy and soldering details, pleasedownload the ON Semiconductor Soldering and Mounting TechniquesReference Manual, SOLDERRM/D. Semiconductor Componen
