View tip29 datasheet:

TIP29 SERIES(TIP29/29A/29B/29C) NPN EPITAXIAL SILICON TRANSISTORMEDIUM POWER LINEARTO-220SWITCHING APPLICATIONS Complementary to TIP30/30A/30B/30CABSOLUTE MAXIMUM RATINGSCharacteristic Symbol Rating Unit Collector Emitter Voltage VCBO 40 V: TIP29 60 V: TIP29A: TIP29B 80 V: TIP29C 100 V: TIP29 Collector Emitter Voltage VCEO 40 V: TIP29A 60 V: TIP29B: TIP29C 80 V1.Base 2.Collector 3.Emitter 100 V Emitter-Base Voltage VEBO 5 V Collector Current (DC) IC 1 A Collector Current (Pulse) IC 3 A Base Current IB 0.4 A Collector Dissipation ( TC=25 ) PC 30 W Collector Dissipation ( TA=25 ) PC 2 W Junction Temperature TJ 150 Storage Temperature TSTG -65 ~ 150 ELECTRICA CHARACTERISTICS (TC =25 )Characteristic Symbol Test Conditions Min Max Unit*Collector Emitter Sustaining Voltage : TIP29 BVCEO(sus) IC = 30mA, IB = 0 40 V : TIP
