View tip2955 datasheet:

TIP2955PNP SILICON POWER TRANSISTOR Designed for Complementary Use with the SOT-93 PACKAGE(TOP VIEW)TIP3055 Series 90 W at 25C Case TemperatureB1 15 A Continuous Collector CurrentC 2 Customer-Specified Selections Available3EPin 2 is in electrical contact with the mounting base.MDTRAAAabsolute maximum ratings at 25C case temperature (unless otherwise noted)RATING SYMBOL VALUE UNITCollector-base voltage (IE = 0) VCBO -100 VCollector-emitter voltage (IB = 0) (see Note 1) VCER -70 VEmitter-base voltage VEBO -7 VContinuous collector current IC -15 AContinuous base current IB -7 AContinuous device dissipation at (or below) 25C case temperature (see Note 2) Ptot 90 WContinuous device dissipation at (or below) 25C free air temperature (see Note 3) Ptot 3.5 WUnclamped inductive load energy (see Note 4) LIC2 62.5 mJOperat
