View tip2955f tip3055f datasheet:

Continental Device India LimitedAn ISO/TS 16949, ISO 9001 and ISO 14001 Certified CompanyPOWER TRANSISTORS TIP2955F PNPTIP3055F NPNTO- 3P Fully IsolatedPlastic PackageBCEDesigned for General Purpose Switching and Amplifier ApplicationsABSOLUTE MAXIMUM RATINGS DESCRIPTION SYMBOL VALUE UNITCollector-Emitter Voltage VCEO 60 VCollector-Emitter Voltage VCER 70 VCollector-Base Voltage VCB 100 VEmitter-Base Voltage VEB 7.0 VCollector Current - Continuous IC 15 ABase Current IB 7.0 ATotal Power Dissipation upto Tc=25 C PD 90 WDerate above 25 C 0.72 W/ CTj, TstgOperating And Storage Junction - 65 to +150 CTemperature RangeTHERMAL RESISTANCE From Junction to case Rth (jc) 1.39 C/WRth (ja) From Junction to Ambient 35.7 C/WELECTRICAL CHARACTERISTICS (Tc=25C unless specified otherwise)DESCRIPTION SYMBOL TEST CONDITION MIN TYP MA
