View tip29 tip30 a b c datasheet:

Continental Device India LimitedAn ISO/TS 16949, ISO 9001 and ISO 14001 Certified CompanyPLASTIC POWER TRANSISTORS TIP29, A, B, C NPNTIP30, A, B, C PNPTO-220Plastic PackageComplementary Silicon Transistors intended for a wide variety of Switching and Amplifier Applications, Series and Shunt Regulators, Driver and Output stages of Hi-Fi AmplifiersABSOLUTE MAXIMUM RATINGS (Ta=25C)TIP29 TIP29A TIP29B TIP29CDESCRIPTION SYMBOL UNITTIP30 TIP30A TIP30B TIP30CVCEO Collector Emitter (sus) Voltage 40 60 80 100 VCollector Base Voltage VCBO 40 60 80 100 VEmitter Base Voltage VEBO 5.0 VCollector Current Continuous IC 1.0 AICMCollector Current Peak 3.0 AIBBase Current 0.4 APower Dissipation upto Tc=25C PD 30 WPower Dissipation upto Ta=25C PD 2.0 WDerate above 25C 16 mW/CTstgStorage Temperature - 65 to +150 CTj Junction Temperature 15
