View tip29a-tip29c tip30a-tip30c datasheet:

TIP29A/29CTIP30A/30CCOMPLEMENTARY SILICON POWER TRANSISTORS STMicroelectronics PREFERREDSALESTYPES COMPLEMENTARY PNP - NPN DEVICES DESCRIPTION The TIP29A and TIP29C are siliconEpitaxial-Base NPN power transistors mounted inJedec TO-220 plastic package. They are intentedfor use in medium power linear and switching32applications.1The complementary PNP types are TIP30A andTIP30C respectively.TO-220INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitNPN TIP29A TIP29CPNP TIP30A TIP30CVCBO Collector-Base Voltage (IE = 0) 60 100 VVCEO Collector-Emitter Voltage (IB = 0) 60 100 VVEBO Emitter-Base Voltage (IC = 0) 5 VI Collector Current 1 ACI Collector Peak Current 3 ACMI Base Current 0.4 ABPtot Total Dissipation at Tcase 25 oC 30 W2 W Tamb 25 oCoT Storage Temperature -65 to 150 Cst
