INCHANGE SemiconductoriscN-Channel MOSFET Transistor TK10A60D5ITK10A60D5FEATURESLow drain-source on-resistance:RDS(on) = 0.8 (typ.)Enhancement mode:Vth = 2.5 to 4.5V (VDS = 10 V, ID=1.0mA)100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRITIONSwitching Voltage RegulatorsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 600 VDSSV Gate-Source Voltage 30 VGSI Drain Current-Continuous 10 ADI Drain Current-Single Pulsed 40 ADMP Total Dissipation @T =25 45 WD CT Max. Operating Junction Temperature 150 jStorage Temperature -55~150 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNITChannel-to-case thermal resistance/WRth(ch-c) 2.78Channel-to-ambient thermal resistance/WRth(ch-a) 62.51
