View tmp3n80 tmpf3n80 datasheet:

TMP3N80/TMPF3N80 TMP3N80G/TMPF3N80G VDSS = 880 V @Tjmax Features ID = 3A Low gate charge RDS(ON) = 4.2 W(max) @ VGS= 10 V 100% avalanche tested Improved dv/dt capability RoHS compliant Halogen free package JEDEC Qualification D G S Device Package Marking Remark TMP3N80 / TMPF3N80 TO-220 / TO-220F TMP3N80 / TMPF3N80 RoHS TMP3N80G / TMPF3N80G TO-220 / TO-220F TMP3N80G / TMPF3N80G Halogen Free Absolute Maximum Ratings Parameter Symbol TMP3N80(G) TMPF3N80(G) Unit Drain-Source Voltage VDSS 800 V Gate-Source Voltage VGS 30 V TC = 25 3 3 * A Continuous Drain Current ID TC = 100 1.83 1.83 * A Pulsed Drain Current (Note 1) IDM 12 12* A Single Pulse Avalanche Energy (Note 2) EAS 283 mJ Repetitive Avalanche Current (Note 1) IAR 3 A Repetitive Avalanche Energy (Note 1) EAR 9.4 mJ TC = 25 94 32 W Powe
