View 2sk2441 datasheet:

Ordering number:ENN4984A N-Channel Silicon MOSFET 2SK2441 Ultrahigh-Speed Switching Applications Features Package Dimensions · Low ON resistance. unit:mm · Ultrahigh-speed switching. 2116 · 2.5V drive. [2SK2441] 8 5 1 : Source 2 : Source 3 : Source 14 0.2 4 : Gate 5.0 5 : Drain 6 : Drain 7 : Drain 8 : Drain 0.595 1.27 0.43 SANYO : SOP8 Specifications Absolute Maximum Ratings at Ta = 25?C Parameter Symbol Conditions Ratings Unit Drain-to-Source Voltage VDSS 20 V Gate-to-Source Voltage VGSS ±12 V Drain Current (DC) ID 7 A Drain Current (Pulse) IDP PW? 10µ s, duty cycle? 1% 48 A Allowable Power Dissipation PD Mounted on ceramic board (1000mm2? 0.8mm) 2.0 W ?C Channel Temperature Tch 150 Storage Temperature Tstg –55 to +150 ?C Electrical Characteristics a
