d2fs6

SHINDENGEN Schottky Rectifiers (SBD) Single OUTLINE DIMENSIONS Case 2F D2FS6 Unit mm 60V 1.5A FEATURES Small SMT Tj150 PRRSM avalanche guaranteed APPLICATION Switching power supply DC/DC converter Home Appliances, Office Equipment Telecommunication RATINGS Absolute Maximum Ratings (If not specified Tl=25 ) Item Symbol Conditions Ratings Unit Storage Temperature Tstg -40 150 Operating Junction Temperature Tj 150 V Maximum Reverse Voltage RM 60 V Repetitive Peak Surge Reverse Voltage VRRSM Pulse width 0.5ms, duty 1/40 65 V I Average Rectified Forward Current O 50Hz sine wave, R-load Ta=31 On alumina substrate 1.5 A 50Hz sine wave, R-load Ta=26 On glass-epoxy substrate 1.1 Peak Surge Forward Curren... See More ⇒
