jmpc25n60bj.pdf datasheet:
600V, 25A, 282m N-channel Power Planar MOSFETJMPC25N60BJProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TestedVDSS 600 V 100% Vds TestedVGS(th)_Typ 3.0 V Halogen-free; RoHS-compliantID(@VGS=10V) 25 ARDS(ON)_Typ(@VGS=10V 282 mWApplications Load Switch PWM Application Power ManagementDG STO-220C-3L Top ViewSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Tube(pcs)(pcs)JMPC25N60BJ TO-220C-3LJMPC25N60BJ N/A Tube 50 5000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 600 VVGS Gate-to-Source Voltage 30 VTC = 25 25CIDContinuous Drain Current ATC = 100 16CIDM Refer to Fig.4 APulsed Drain Current (1)EAS 1080 mJSingle
