jmsh0406ag.pdf datasheet:

jmsh0406agjmsh0406ag

JMSH0406AG40V 4.1m N-Ch Power MOSFETProduct SummaryFeatures Ultra-low ON-resistance, RDS(ON)Parameter Value Unit VDS Low Gate Charge, Qg 40 V VGS(th)_Typ2.8 V 100% UIS and Rg Tested ID (@ VGS = 10V) (1) 86 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)4.1 m Halogen-free and RoHS-compliantApplications Power Management in Computing, CE, IE 4.0, Communications Current Switching in DC/DC & AC/DC (SR) Sub-systems Load Switching, Quick/Wireless Charging, Motor DrivingPDFN5x6-8LPin ConfigurationTop ViewBottom ViewTop ViewD1827G 3645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH0406AG-13 PDFN5x6-8L 8 SH0406A 1 -55 to 150 13-inch Reel 5000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-
