jmsh1010pg.pdf datasheet:
100V, 75A, 7.3m N-channel Power SGT MOSFETJMSH1010PGProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TestedVDSS 100 V 100% Vds TestedVGS(th)_Typ 2.9 V Halogen-free; RoHS-compliantID(@VGS=10V) 75 ARDS(ON)_Typ(@VGS=10V 7.3 mWApplications Load Switch PWM Application Power ManagementDG SPDFN5X6-8LSchematic DiagramPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMSH1010PG PDFN5x6-8LSH1010P 1 Tape&Reel 5000 50000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage 100 VVGS Gate-to-Source Voltage 20 VTC = 25 75CIDContinuous Drain Current ATC = 100 47CIDM Refer to Fig.4 APulsed Drain Current (1)EAS 165 mJSingle Pulsed Avalan
