jmsh1509ag.pdf datasheet:

jmsh1509agjmsh1509ag

JMSH1509AG150V 8.5m N-Ch Power MOSFETFeatures Product SummaryParameter Typ. Unit Ultra-low RDS(ON) VDS150 V Low Gate Charge VGS(th)3.2 V 100% UIS Tested, 100% Rg Tested ID (@ VGS = 10V) (1) 75 A Pb-free Lead Plating RDS(ON) (@ VGS = 10V)8.5 m Halogen-free and RoHS-compliantApplications Power Managerment in Telecom., Industrial Automation, CE Current Switching in DC/DC & AC/DC (SR) Sub-systems Motor Driving in Power Tool, E-vehicle, RoboticsPDFN5x6-8L Pin ConfigurationBottom View Type-A Bottom View Type-BTop ViewDTop View1827G 3645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1509AG-13 PDFN5x6-8L 8 SH1509A 1 -55 to 150 13-inch Reel 5000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-
