jmsh1535ag.pdf datasheet:

jmsh1535agjmsh1535ag

JMSH1535AG150V 27m N-Ch Power MOSFETProduct SummaryFeaturesParameter Value Unit Low ON-resistance, RDS(ON) VDS150 V Low Gate Charge, Qg VGS(th)_Typ3.3 V 100% UIS and Rg Tested ID (@ VGS = 10V) (1) 28 A Pb-free Lead Plating RDS(ON)_Typ (@ VGS = 10V)27 m Halogen-free and RoHS-compliantApplications Power Management in Telecom., Industrial Automation, CE Current Switching in DC/DC & AC/DC (SR) Sub-systems Motor Driving in Power Tool, E-vehicle, RoboticsPDFN5x6-8LPin ConfigurationTop ViewBottom ViewTop ViewD1827G 3645SOrdering InformationDevice Package # of Pins Marking MSL TJ (C) Media Quantity (pcs)JMSH1535AG PDFN5x6-8L 8 SH1535A 1 -55 to 150 13-inch Reel 5000Absolute Maximum Ratings (@ TA = 25C unless otherwise specified)Parameter Symbol Value UnitDrain-to-Source Voltage V
