jmtg050p03a.pdf datasheet:
-30V, -80A, 5.2m P-channel Power Trench MOSFETJMTG050P03AProduct SummaryFeatures Excellent RDS(ON) and Low Gate ChargeParametersValue Unit 100% UIS TESTEDVDSS -30 V 100% Vds TESTEDVGS(th)_Typ -1.7 V Halogen-free; RoHS-compliantID(@VGS=-10V) -80 A Pb-free platingRDS(ON)_Typ(@VGS=-10V 3.7 mWRDS(ON)_Typ(@VGS=-4.5V 5.2 mWApplications Load Switch PWM Application Power ManagementDGSSchematic DiagramPDFN5x6-8LPin AssignmentOrdering InformationPer CartonDevice PackageMarking MSL Form Reel(pcs)(pcs)JMTG050P03A PDFN5x6-8LG050P03A 1 Tape&Reel 5000 50000Absolute Maximum Ratings (@ TC = 25C unless otherwise specified)Parameter ValueSymbol UnitVDS Drain-to-Source Voltage -30 VVGS Gate-to-Source Voltage 20 VTC = 25 -80CIDContinuous Drain Current ATC = 100 -57CIDM Refer to Fig
