Product Data SheetFebruary 1, 2002Discrete MESFET TGF1350-SCCKey Features and Performance 0.5 um x 300 um FET 1.5 dB Noise Figure with 11dB AssociatedGain at 10 GHz 2.5 dB Noise Figure with 7 dB AssociatedGain at 18 GHz All-Gold Metallization for High Reliability Recessed Gate Structure 0.620 x 0.514 x 0.102 mm (0.024 x 0.020 x0.004 in.)DescriptionThe TriQuint TGF1350-SCC is a single-gate GaAs field-effect transistor (FET) usedfor low-noise applications DC to 18 GHz. Bond pad is gold plated for compatibilitywith thermocompression and thermosonic compatibility wire-bonding processes.The TGF1350-SCC is readily assembled using automated equipment. Die attachshould be accomplished with conductive epoxy only. Eutectic attach is notrecommended .1TriQuint Semiconductor Texas : (972)994 8465 Fax: (972)994 8504 Web: www.triquint.com
