ap20gt60p-hf.pdf datasheet:

ap20gt60p-hfap20gt60p-hf

AP20GT60P-HFHalogen-Free ProductAdvanced Power N-CHANNEL INSULATED GATEElectronics Corp. BIPOLAR TRANSISTORFeaturesVCES 600V High Speed Switching IC 20AG Low Saturation VoltageTO-220(P)CEVCE(sat),typ.=1.8V@IC=20AC RoHS Compliant & Halogen-FreeGEAbsolute Maximum RatingsSymbol Parameter Rating UnitsVCESCollector-Emitter Voltage 600 VVGEGate-Emitter Voltage +20 VIC@TC=25oCCollector Current 40 AIC@TC=100oCCollector Current 20 AICMPulsed Collector Current1 160 APD@TC=25oCMaximum Power Dissipation 104 W oTSTGStorage Temperature Range -55 to 150 CoTJOperating Junction Temperature Range 150 CNotes:1.Pulse width limited by Max. junction temperature .Thermal DataSymbol Parameter Value UnitsoRthj-c Thermal Resistance Junction-Case 1.2 C/WoC/WRthj-a Thermal Resistance Junction-Ambient 62Electrical
