irf1405zs.pdf datasheet:

irf1405zsirf1405zs

Isc N-Channel MOSFET Transistor IRF1405ZSFEATURESWith To-263(D2PAK) packageLow input capacitance and gate chargeLow gate input resistance100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSwitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 55 VDSSV Gate-Source Voltage 20 VGSSDrain Current-ContinuousTc=25150I AD110Tc=100I Drain Current-Single Pulsed 600 ADMP Total Dissipation @T =25 230 WD CT Max. Operating Junction Temperature 175 chStorage Temperature -55~175 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 0.65/WRth(ch-a) Channel-to-ambient thermal resistance 621isc websitewww.iscsemi.cn isc & is
