LESHAN RADIO COMPANY, LTD.Bas Resstor TransstorNPN Silicon Surface Mount Transistorwith Monolithic Bias Resistor NetworkLMUN2211LT1G SeriesS-LMUN2211LT1G SeriesThis new series of digital transistors is designed to replace a singledevice and its external resistor bias network. The BRT (Bias ResistorTransistor) contains a single transistor with a monolithic bias network3resistor. The BRT eliminates these individual components byintegrating them into a single device. The use of a BRT can reduce1both system cost and board space. The device is housed in the SOT-232package which is designed for low power surface mount applications. Simplifies Circuit DesignSOT23 (TO236AB) Reduces Board Space and Component Count The SOT-23 package can be soldered using wave or reflow. The PIN 3R1 COLLECTORmodified gull-winged leads absorb thermal
