sft1443.pdf datasheet:

SFT1443Ordering number : ENA1896SANYO SemiconductorsDATA SHEETN-Channel Silicon MOSFETGeneral-Purpose Switching DeviceSFT1443ApplicationsFeatures ON-resistance RDS(on)1=180m (typ.) Input Capacitance Ciss=490pF(typ.) 4V drive Halogen free complianceSpecifications at Ta=25CAbsolute Maximum RatingsParameter Symbol Conditions Ratings UnitDrain-to-Source Voltage VDSS 100 VGate-to-Source Voltage VGSS 20 VDrain Current (DC) ID 9 ADrain Current (Pulse) IDP PW10s, duty cycle1% 36 A1 WAllowable Power Dissipation PDTc=25C19 WChannel Temperature Tch 150 CStorage Temperature Tstg --55 to +150 CPackage Dimensions Package Dimensions unit : mm (typ) unit : mm (typ)7518-004 7003-0042.36.56.5 2.35.0 0.55.0 0.5440.850.50.850.71.21 2 30.6 0.50.6 0 to 0.21 : Gate 1 : Gate1.22 :
